Flat Screen Printing Machine

Shenzhen Topper Printing Machinery Co.,Ltd is one of the most experienced manufacturers and suppliers of flat screen printing machine in China. Please feel free to wholesale high quality equipment at competitive price from our factory. Customized orders are welcome.





[ PRODUCT INFORMATION ]

This flat screen printing machine is suitable for sheet material for screen printing, the printing equipment is widely used in flat surface product printing, like plastic panel, plastic sheet/ film, appliance panel and cover, fabric, aluminum sheet, paper sheet, PVC, PCB board, glass, lens, PC composite board, Acrylic sheet, membrane switch, PCB etc.

[ PRODUCT FEATURE ]

Feature

1. Motor driven vertical screen lifting system .

2. Micro PLC control panel with easy operation.

3. Servo motor and HIWIN liner guide drive left-right precise print.

4. Adopt Air TAC electronic parts to make sure machine quality.

5. The position of mesh frame can be adjusted from front to back, left and right, and horizontally

6. Scraper constant pressure device to ensure stable pressure in printing process

7. Install slider and liner guider to move the frame holder, easy to install the mesh frame.

8. This 1 color screen printing press with vacuum worktable.

9. Adjust the front and rear, left and right of the worktable, and adjust the horizontal height



[ PRODUCT SPECIFICATION ]

Model	TS-5070P
Worktable Size	600x800mm
Max. Printing Size	500x700mm
Max. Screen Frame Size	700x1000mm
Max. Substrate Height	50mm
Max. Printing Speed	1200pcs/hr
Air Pressure	6bar
Rated Voltage	220V 50Hz
Power	2.2kws



[ PRODUCT APPLICATION ]

Pad printers and screen printers suitable for printing in plastic rubber, metal glass, ceramic wood products and other materials, widely used in glass cosmetics, stationery office supplies, electronic appliances, process decoration, medicine, ceramics and other fields. Can print exquisite effect on the plane, sphere and surface such as pen ruler, makeup bottle, glass bottle, industrial glove, fishing rod lamp tube long rod, glass touch screen, film circuit, electronic parts, keypad, medical tube, chip, memory card, computer mobile phone furniture tool shell and so on.





[ COMPANY PROFILE ]



[ CERATIFICATIONS ]



[ SHIPPING ]

(1) Internal: Plastic stretch film wraps the entire machine.

(2) Middle: The machine is fixed with tie ropes and screws to prevent the machine from tilting during transportation and reduce machine shaking.

(3) Outside: standard export wooden case, plywood case for each machine.



[ SALES SERVICES ]

[ FAQ ]

Q1. Are you a factory or a trading company?

A: We are a factory specializing in the production of printing equipment. Integrating research, design, production, development and sales, with the tenet of "pragmatism and innovation", the principle of "honesty and pragmatism", and the exquisite design and perfect technical support to serve our customers.



Q2: Do you provide customized services?

A: According to customer requirements, we can design and produce the equipment required by customers. we accept customization, for example, adding anti-dust cover, drying oven, tunnel furnace, UV curing machine, feeding direction, loading and unloading direction, etc.



Q3. Why choose us?

1. 20 years professional production experience in printing punching machinery industry.

2. Strong production capacity.

3. Professional senior engineer develop the best solution.

4. Strict quality control system, CE certificate available.

5. Main components adopt imported international famous brand.

6. Professional after-sale service, Email will be reply in 24 hours.



Q4: Is it complicated to install and debug the machine?

A: This machine is fully assembled, so it is easy to operate.
