Plastic Crate Automatic Screen Printing Machine With Drying
4-sided rotating plastic create screen printer machine, supporting rotating printing on 2 or 4 sides.Fully automated form, achieving a complete printing production line.
Description
Shenzhen Topper Printing Machinery Co.,Ltd is one of the most experienced manufacturers and suppliers of plastic crate automatic screen printing machine with drying in China. Please feel free to wholesale high quality equipment at competitive price from our factory. Customized orders are welcome.
Complete Crates Printing Solutions
4 Sides rotary crates screen printing machine
4-sided rotating plastic create screen printer machine, supporting rotating printing on 2 or 4 sides.Fully automated form, achieving a complete printing production line.
Auto flame treatment conveyor belt
For PP or PE materials, flame treatment is required before printing. Can independently control the speed of the conveyor belt and adjust the feeding direction according to different crates,Connect with the feeding part of the Crate screen printing machine.
IR Drying conveyor belt
The completed crates, dried by IR, can make the ink printed on the product dry and firm. Connected to the unloading section of the Crate screen printing machine
Plastic Crate Automatic Screen Printing Machine With Drying Details
Printing Stations
Using servo controlled printing station to achieve precise printing
auto loading robot arm
After flame treatment, the crate is placed on the first printing station by the auto loading robot arm
Auto flame treatment
PE, PP or glass materials require flame treatment before printing to ensure better adhesion of the ink
auto unloading robot arm
Cowers Commercial Cleaning Robot Landing Case:China Mobile Software Park
Servo rotary fixture
According to the size of the crates , directly use a fixed fixture for rotary printing
servo shuttle worktable
The crates printed at the second workstation are taken and placed on the drying conveyor belt by the automatic unloaing arm
Machine data sheet & Feature
Model
TS-3040C2
Max frame size
400x600mm
Max. Printing size
300x400mm
Printing height
350 mm
Max. Printing Speed
250pcs/hr
Printing color
2
Servo motor and driver quantity
12 sets
Rated Voltage
380V,3phases
Air Pressure
5-7 bar
Printing side
4
Dimension(L×W×H)
2500*1600*1920mm
Weight
1500kgs
Operation panel
PLC+touch screen panel for easy operation
Machine design
Parallel load and unload conveyor design for save space
Servo rotary
Servo motor rotate the crate for print 2 sides
Automatic printing line
Servo robot arm to load & unload the crate into fixture for printing
Servo shuttle worktable
Servo shuttle move the crate from 1 printing station to another
Rotary printing
Servo rotate the crate side on the conveyor for drying
Flame pre-treatment
Equip with 4 side flame pretreated device for PP/PE crate
Detect system
Auto detecting system, without crate without printing
High temperature dryer
With IR drying oven system
