Automatic Screen Press Machine
The automatic screen press machine is special designed for printing ruler with high speed and automatic. Building up printing and conveying system by high precision motor to finish printing automatically, reduce labor, improving efficiency. suitable for printing rulers within 60cm.
Description
Shenzhen Topper Printing Machinery Co.,Ltd is one of the most experienced manufacturers and suppliers of automatic screen press machine in China. Please feel free to wholesale high quality equipment at competitive price from our factory. Customized orders are welcome.
An Automatic Screen Printing Machine, or automatic screen press, is a specialized printing device used in the screen printing process. This machine automates the steps involved in screen printing, a technique where ink is transferred through a mesh screen onto a substrate, such as fabric or paper, to create a printed design. Automatic screen presses are designed for high-volume production, offering efficiency by automating tasks like ink application, substrate loading, and color registration. These machines are commonly employed in the production of items like T-shirts, posters, and signage, streamlining the printing process and improving consistency in large-scale manufacturing.
We are a leading manufacturer and supplier of screen printing machines established in 2003. Initially, we focused on pad printing machines and introduced the TPM brand. Our main markets are in Europe and Southeast Asia. We have several agency offices in Czech, Romania, Greece, Sweden, Vietnam, Indonesia, and the Philippines.
We pride ourselves on providing exceptional quality machines to our customers. Before the order is placed, we provide machine drawings for customers to approve. For every machine, we install high-quality electronic components from Japan and Europe, mainly from SMC, Mitsubishi, Omron, and Schneider. After the machine is ready, we have three QC workers to inspect the machine and ensure that it is in working order before shipping.
Our services
1. 2 hours online reply in working daytime
2. 12 hours quote confirm
3. 100% quality strictly checked
4. Secure logistics forwarder
5. One year warranty and life time maintenance
6. Have a self-developed technical production line
7. Ability to machine customization
Our products
Our automatic screen printing machine is a game-changer in the printing industry. With stability, precision, and safety as our guiding principles, you can be sure that our machine will deliver consistent, reliable, and high-quality prints every time.
Product specifications
|
Model: |
TS-60RS1 |
|
Worktable Selection: |
Vacuum |
|
Worktable Size: |
150x800mm |
|
Max. Printing Size: |
100x700mm |
|
Max. Screen Frame Size: |
400x900mm |
|
Max. Substrate Height: |
150mm |
|
Max. Printing Speed: |
1500pcs/hr |
|
Air Pressure: |
6bar |
|
Rated Voltage: |
220V 50Hz |
|
Power: |
2kw |
|
Dimension(L×W×H): |
1800x900x1750mm |
|
Weight: |
400kg(Approx.) |
Product features
1. Fully automatic
Our machine requires no specialized personnel to operate it. It is easy to use and efficient, saving you time and money.
2. Automatic positioning
We pride ourselves on our ability to maintain printing accuracy. Our machine is designed with automatic positioning that ensures your prints are always on target.
3. Printing stability
Without a printing system, there can be no product. Our machine is engineered to provide stability and consistency in your printing process.
4. High-strength vacuum system
Our machine is equipped with a high-strength vacuum system that guarantees precision in every print.
5. 1-color printing of up to 60cm
Our machine can print up to 60cm long straight edges with one color.
6. PLC and touch screen control system
Our machine is designed with a digital control system that allows you to easily set the required parameters, making operation a breeze.
7. Convenient setting
With our machine, adjusting printing angle, pressure, and mesh distance is a breeze. The scraper and water stop bar are controlled by precision rails, ensuring that they remain vertical and stable.
8. Emergency stop switch
Safety is our topmost priority. We have integrated an emergency stop switch into our machine to ensure safety and stability.
9. precision rotating positioning
Our machine is equipped with Taiwan's precision rotating positioning technology, which allows for multiple accurate positioning. It is fast, stable, and highly efficient.
Product operation steps
Step 1: The design is created.
To start, the screen printer takes the design they want to create on the finished product and prints it out onto a transparent acetate film. This will be used to create the stencil.
Step 2: The screen is prepared.
Next, the screen printer will choose a mesh screen to suit the complexity of the design and the texture of the fabric being printed. The mesh screen is then coated with a layer of light-reactive emulsion, which will harden when developed under bright light.
Step 3: The emulsion is exposed.
The acetate sheet featuring the design is then laid onto the emulsion-coated screen, and the whole thing is exposed to very bright light. The light hardens the emulsion so the parts of the screen which are covered by the design remain in a fluid form.
Step 4: The emulsion is washed off, creating the stencil.
After the screen has been exposed for a set time, the areas of the screen not covered by the design will have turned hard. Any unhardened emulsion is then carefully rinsed away. This leaves a clear imprint of the design on the screen for the ink to pass through. The screen is then dried, and the screen printer will make any necessary touch-ups or corrections to make the imprint as accurate as possible to the original design. The stencil is now ready to be used.
Step 5: The item is prepared for print.
To start, the printer takes the design they want to create on the finished product and prints it out onto a transparent acetate film. This will be used to create the stencil.
Step 6: The ink is pressed through the screen onto the item.
The screen is lowered down onto the printing board, ink is added to the top end of the screen, and a squeegee is used to pull the ink along the full length of the screen. This presses the ink through the open areas of the stencil, imprinting the design on the product underneath when developed under bright light.
Step 7: To check the printed quality.
The printed product then passes through a dryer, which "cures" the ink and creates a smooth, color-fast finish. The final product will be checked and washed thoroughly to remove any residue before being passed on to its new owner.
What is the difference between Automatic Screen Press Machine and normal printing?
Automatic screen press machine is a modern printing technology that offers various benefits when compared to traditional printing methods. The primary difference between automatic screen press machine and normal printing is the process involved in creating the prints.
In traditional printing, images are transferred onto paper by means of a printing plate or a roller, which is then pressed onto the paper. This method is labor-intensive and time-consuming, which limits the number of prints that can be made efficiently. Moreover, traditional printing doesn't offer the same level of detail and precision that automatic screen press machine provides.
On the other hand, an automatic screen press machine is designed to print high-quality graphics on various materials, including fabric, paper, and plastic. It works by pushing ink through a mesh screen, which is coated with a stencil of the design to be printed. The machine accurately aligns the screen with the material and applies the ink in a consistent manner. This process ensures that each print is of the same quality and the results are always consistent.
In addition, automatic screen press machines can produce bright and vivid colors, thanks to the use of advanced printing inks. The colors are rich, long-lasting, and don't fade quickly, making them ideal for creating high-quality prints.
Moreover, the automatic screen press machine is capable of printing an extensive range of designs with great speed and efficiency. This means that businesses can print a large number of prints in a short amount of time at a low cost, which is ideal for mass production.
How much does it cost to buy an automatic screen printing machine?
Screen printing machines are commonly used in the printing industry, and their prices vary based on factors such as type, level of automation, materials, brand, configuration, features, and specifications. The cost can range from as low as a couple of hundred dollars for basic models to tens or even hundreds of thousands of dollars for large, high-end screen printing machines. When purchasing a screen printing machine, it's essential to consider printing requirements, product quality, and cost-effectiveness. If you would like more detailed information, please leave us a message with your email and phone number, and we will contact you promptly.
How fast is a screen printing machine?
Max. Printing Speed:1500pcs/hr
How hard is it to learn screen printing?
It is not very difficult to learn screen printing, it just requires patience. Most of the designs are just simple outlines, but more complex designs require more patience. Your question lacks proper understanding, as with anything, there are easy and difficult parts to screen printing. As long as you are able to use design software, then any screen printing design can be achieved. And if you are willing to learn and put in effort, there is nothing that you can't learn.
What are the common types of automatic silk screen machines?
1. Flatbed Automatic Screen Printing Machine
This is the most common type of automatic silk screen machine. It is ideal for printing on flat substrates such as paper, plastic, and metal. This machine consists of a flat bed where the substrate is placed, and a screen is lowered onto the substrate to transfer the ink.
2. Rotary Automatic Screen Printing Machine
This machine is designed for printing on cylindrical objects such as bottles and tubes. It has a rotating platform that holds the substrate and moves it through the printing process. This type of machine is ideal for high-volume printing of cylindrical objects.
3. Three-quarter Automatic Screen Printing Machine
This type of machine is a hybrid between a manual and an automatic machine. It requires some manual intervention, but most of the process is automated. This machine is ideal for printing on irregular shapes or surfaces.
4. Full Automatic Screen Printing Machine
This is the most advanced type of automatic silk screen machine. It is fully automated, from loading the substrate to printing and unloading the finished product. This type of machine is ideal for high-volume production of flat substrates.
