Plastisol Transfer Printer Machine

Shenzhen Topper Printing Machinery Co.,Ltd is one of the most experienced manufacturers and suppliers of plastisol transfer printer machine in China. Please feel free to wholesale high quality equipment at competitive price from our factory. Customized orders are welcome.





This Plastisol transfer printer machine is a latest automatic foil stamping equipment. It is widely used in heat transfer stamping with various kinds of flat flat materials, such as invitation card, caps, cartons,leather. With heat transfer machine, the products can be made with more personalization and more exquisite.



1. With the crank design,which has powerful stamping pressure and little consumption of air pressure.
2. Worktable is adjustable in front-back,left-right direction and revolvable,which ensures the quick and safe operation.
3. Stamping pressure,temperature and time are adjustable.
4. Automatic foil feeding and rolling with adjustable function.
5. Height of the stamping head is adjustable.

6.Servo control is used on the left and right sides of the worktable, with precise movement and low noise.





Model	TH-300CP
Operation	PLC+ touch screen panel
Heating roll silicon size	Dia.60xL100mm
Max. stamping temperature	150-200℃
Stamping size	70mm
Stamping pressure	300kgs
Max. stamping size	100*100mm
Heating plate	150x150mm
Max. printing speed	800pcs/hr
Dimension(L×W×H)	1500x1000x1780mm
Weight	380kgs



1.Stamping foil/heat transfer film

The hot stamping process is based on the principle of hot pressing transfer, so that the surface of the substrate is formed.

2.Holding fixtures

The bronzing fixture is used to fix the load so that it does not shake randomly.

3.Silicon / copper dies

Hot stamping silicon die transfers the delicate pattern to the product by using the silicone board as a heat carrier.





Inside packaging
Packing with waterproof film and with several layers of shrinking film for 360degree package. To ensure the machine is 100% clean when customer unpack it.

Outside packaging
With tri-ply wooden case packing, the wood pallet material as fumigation wooden. It is strong fix wooden case for sea shipment.



Q1:Where is your product use in?

A. Our machines can be used for products that can be seen everywhere in our life.

As long as there is a need for printing, we can use our machines in a wide range of applications.



Q2:Can you produce conveyor as our requirements?
A. Yes, OEM is available. We have professional team to do anything what you want from us.
